Use Dependency shapes to indicate the relationships between components or between one component and another component's interface. To change the type of shape that displays for an interface, right-click the Interface shape and click Show as Class-like Interface or Show as Lollipop Interface.
Use this shape when you want to display a list of the interface operations. You can also represent an interface with a rectangular Interface shape that resembles a class. Glue the endpoint without the circle to a connection point on the class component, or other element.ĭouble-click the Interface shape to add a name, operations, and other property values. In a static structure, component, or deployment diagram, drag the lollipop Interface shape onto the drawing page. Where appropriate, drag an Interface shape onto the drawing page and glue the endpoint without the circle to a component shape.Īdd an interface to a class, component, or other elements Note: If the tree view isn't visible, point to View on the UML menu, and then click Model Explorer.ĭrag a Component shape onto the drawing page for each component you want to represent. To move the text independently of the shape, go back to the Text Block Tool. If you use the Pointer Tool to drag the text, the shape will also move. When you’re done, click the Pointer Tool buttonĪfter you switch back to the Pointer Tool button, the text keeps the same position relative to the shape. On the Home tab, in the Tools group, click the Text Block toolĬlick the connector that has text your want to rotate or move.ĭrag the text block to move it, or rotate it using the Rotation Handle
Battleship online game 2 player how to#
Here’s how to do that:Ĭlick an empty area of the page to deselect anything that may be selected. Most likely you’ll need to rotate or move text on your connector lines. If you anticipate moving shapes a lot, consider making a dynamic connection instead of a point connection. Make dynamic connections instead of point connections Right-click the connector, and then click Set Connector Type. For example, you can change from an Association to a Directed Association. If you do not need all the text boxes, delete the ones you don’t need. When you’re done, four text boxes appear where you can add details. If needed, right-click the connector and select Show Multiplicity. If a connector is taking too many turns, right-click it, and then click Straight Connector.
